What you need to know



    Principle of Luminescence

    • Non-enzyme involved flash chemiluminescence, long stability of reagents
    • ABEI label, stable in acid and alkaline solution

    Modes of Operation

    • Random, Batch and STAT

    Sample Loading

    • Up to 40 sample tubes
    • Continuous loading, STAT available
    • Analyzer auto numbered
    • LIS connection
    • Refrigerated sample area with independent power supply

    Reagent Loading

    • 9 reagents on board
    • Continuous loading
    • RFID reading all info of reagents
    • Refrigerated reagent area

    Reagent Features

    • Integrated kit, ready-to-use, no pretreatment required
    • Integrated kit including calibrators
    • Using super paramagnetic micro beads
    • RFID tag storing all info of reagent
    • RFID tag with built-in master curve
    • 2-point calibration to adjust master curve
    • Calibration stability: Max 4 weeks

    Other Features

    • Clot detection
    • Liquid level detection for reagent
    • Optional ratio for sample dilution
    • Auto dilution for high concentration sample
    • Constant 37℃ incubation
    • 15-30℃ Operating Temperature

    Operation System

    • Windows 7, HP compatible (Dual-core CPU), Color touch screen


    • Connection to LIS via COM or network card
    • Direct operation on LIS system to test

    Dimensions Weight

    • 102x72x56cm, 73Kg
